Thinvent® Treo Mini PC, Intel® processor N100 (4 core, up to 3.4 GHz, 6 MB cache), 64GB DDR4 RAM, 1TB SSD, 12V 2A Adapter, No WiFi, Thinux™ Embedded Linux, Mechanical Keyboard
SKU: Treo-100-64-m1024-12_2-X-Thinux-MK
Specifications
Processing
| Cores | 4 |
| Max Frequency | 3.4 GHz |
| Cache | 6 MB |
| Main Memory | 64 GB |
| SSD Storage | 1024 GB |
Display
| HDMI | 1 |
| VGA | 1 |
Audio
| Speaker Out | 1 |
| Mic In | 1 |
| Front Speaker Out | 1 |
| Front Mic In | 1 |
Connectivity
| USB 3.2 Gen 2 | 2 |
| USB 3.2 Gen 1 | 1 |
| USB C | 1 |
| Front USB 2.0 | 4 |
Networking
| Ethernet | 1000 Mbps |
Power
| DC Voltage | 12 Volts |
| DC Current | 2 Amps |
| Power Input | 100~240 Volts AC, 50~60 Hz, 0.9 Amps maximum |
| Cable Length | 1 Metre |
Environmental
| Operating Temperature | 0°C ~ 40°C |
| Operating Humidity | 20% ~ 80% RH, non condensing |
| Certifications | RoHS, ISO, BIS |
Physical
| Dimensions | 199.5mm × 181.5mm × 29.5mm |
| Housing Material | Aluminium |
| Housing Finish | Powder Coated |
| Housing Colour | Black |
Accessories
| VESA Mount | 1 |
Operating System
| Operating System | Thinvent® Thinux™ Embedded Linux |
| OS Features |
|
